MAUP BASE 20 Wall Formwork

Features of BASE 20 Formwork:

• Efficient assembly on-site with large pre-assembled panels, easily handled by crane assistance.
• Versatile design allows adaptation to all sizes and shapes due to the flexible arrangement of girders and walers.
• Achieves fair-faced concrete finishes for architectural applications, using high-quality plywood, minimal tie rods, and joints for smooth, attractive surfaces.

Specifications of BASE 20 Formwork:

• Panel widths determined by the length of the steel waler for optimal stability.
• Panel heights depend on the H20 girder and panel strut length, reaching up to 12 meters for taller structures.
• Adaptable to various fresh concrete pressures, supporting up to 90 kN/sqm, making it suitable for large and heavy-duty projects.
• Customizable shapes are achieved through shaping wood and specially fabricated steel walers, allowing for complex forms and irregular designs.

Applications of BASE 20 Formwork:

• Ideal for residential and commercial buildings, concrete tanks, basements, bridge abutments, piers, and other irregular concrete structures.
• Perfect for both simple and complex architectural designs in a variety of construction projects.
