Slab Flex 20 Formwork

The MAUP Slab Flex 20 formwork offers an exceptional and versatile solution not only for standard slab projects but also for complex designs featuring drop beams and narrow corners. This system is composed of MAUP-Form plywood, H20 timber beams, and shoring props, which can be configured in various positions and arrangements to suit specific project needs.This adaptability makes the Slab Flex 20 particularly valuable for a wide range of construction applications, allowing for efficient assembly while accommodating ...

Features of Slab Flex 20 Formwork

Versatile Design: The Slab Flex 20 formwork is flexible and economical, making it suitable for various ground plans.
Efficient Assembly: It can be assembled efficiently through manual operations, streamlining the construction process.
Customization Options: Users can choose shuttering options based on specific finishing requirements, allowing for greater design flexibility.
Space-Efficient: It is designed for easy transportation and storage, minimizing the space required.
Adaptability: The system can accommodate different beam shapes and sizes, enhancing its applicability across various projects.

Specifications of Slab Flex 20 Formwork

Custom Planning: The girder and prop spacing are determined based on specific project requirements, allowing for tailored solutions.
Shoring Options: Users can select from various shoring options, with recommendations for D class or E class heavy-duty props according to the EN1065 standard.
Thickness Range: The formwork is capable of handling slab thicknesses of up to 1000 mm.
Early Dismantling: An early dismantling system is available for quicker project turnaround.
Installation Components: Includes Beam 20 Bracket and Beam 20 Extension with an easy tightening system using D15 rod and nut for secure assembly.

Applications of Slab Flex 20 Formwork

Suitable for creating slabs and beams in diverse constructions, including:
Buildings and factories
Water tanks
Flyover roads and bridges
For more detailed information, including technical specifications and applications, you might want to refer to manufacturers' websites or construction materials suppliers that provide comprehensive guides on formwork systems.
