MAUP Alu Flex Formwork

Features of Alu-Flex Slab Formwork

• Lightweight and User-Friendly: The formwork's lightweight design and straightforward assembly process              allow for quick and efficient manual operation.
• Cost-Effective Early Stripping: The early stripping head minimizes on-site material needs, leading to                       reduced costs.
• Hygienic and Durable: The high-temperature powder-coated frame allows for easy cleaning and                             maintenance.
• Versatile Applications: Suitable for a wide range of beamless slab projects, including large-area shuttering.

Specifications of Alu-Flex Slab Formwork

• Construction Material: The formwork panel features a frame made from 6082-T6 aluminum alloy, lined with            10mm Maup-Form birch plywood, with a panel depth of 142mm.
• Panel Dimensions: Available in lengths of 1800, 1200, 900, and 750 mm, and widths of 1800, 1200, 900, 750,               and 600 mm.
• Weight: Each Alu-Flex panel weighs approximately 17.6 kg/m².
• Shoring Support: Utilizes medium-duty props, conforming to D class or E class heavy-duty standards                        under EN1065, to accommodate various slab thicknesses of up to 700mm.

Applications of Alu-Flex Slab Formwork

• Ideal for Construction: Perfect for residential and commercial buildings that feature minimal beam designs.
