Aludeck Slab Formwork

Features of Aludeck Slab Formwork

• Lightweight Design: The combination of aluminum panels and TMP multi-purpose aluminum props creates an efficient and effective decking system.
• Quick Deployment: Early stripping heads help reduce material needs on-site, allowing for faster panel installation.
• Easy Maintenance: The high-temperature powder-coated frame ensures that the system is easy to clean.
• High Load Capacity: The TMP aluminum props provide a significant load capacity, enabling the use of fewer slab props (approximately 0.3 per square meter).
• Extendable Props: The multi-purpose TMP aluminum props can be extended to double or triple heights when reinforced with MRK truss braces.

Specifications of Aludeck Slab Formwork

• Material Composition: Panels are constructed from 6061-T6 or 6082-T6 aluminum profiles, lined with 9mm Maup-Form birch, with a depth of 120mm.
• Dimensions:
  • Panel Lengths: 1500mm and 750mm
  • Panel Widths: 750mm, 500mm, and 375mm
  • Main Beam Lengths: 1550mm, 2300mm, and 3800mm
• Weight: Each panel weighs around 15 kg/m².
• Shoring Props: Uses TMP multi-purpose aluminum props that meet D class or E class heavy-duty standards according to EN1065.
• Slab Thickness Capacity:
  • Supports slabs up to 100cm thick with a 150cm main beam and 75cm width panel.
  • Supports slabs up to 40cm thick with a 225cm main beam.
• Props Height Options: Heights available include 1200mm, 2500mm, 3500mm, 4800mm, and 6250mm, with a maximum workload of 90kN.

Applications of Aludeck Slab Formwork

Aludeck Slab Formwork is suitable for a diverse range of projects, including:

• Residential Buildings
• Commercial Structures
• Civil Engineering Projects that require thicker or higher slabs.
